Multifunction Digital Oscilloscope Transistor Tester Function Signal Generator
DSO-TC3
This digital oscilloscope Oscilloscope is suitable for fast pairing transistors, identification of mixed surface mount and wordless components, and preliminary screening of small batch components. It can automatically identify and measure various transistors. Including NPN and PNP transistors, N-channel and P-channel field effect transistors, junction field effect transistors, diodes, dual diodes, thyristors, resistors, inductors, capacitors, and other passive components. Automatic detection of pin definition. Automatically analyze NEC protocol infrared code.
It can also identify device type, pin polarity, hFE, turn-on voltage, junction capacitance; test capacitance, resistance, inductance components, etc.
Features:
Detect problem accurately - basically meet the needs of all component detector
Capture accurately - high sensitivity capture, accurate, and fast
6 major waveforms - Sine wave, Square wave, Pulse wave, Triangle wave, Ramp wave, DC
Drop-proof ABS Shell - resistant to falling and more durable
1500 MAH HQ Polymer Lithium battery - 4H super battery life. Eco-friendly & portable
2.4 inch TFT full-color HD display - visible even in sunlight
Specifications:
Model: DSO-TC3
Display screen：2.4 inch TFT color screen, LED backlight
Supply voltage： Rechargeable lithium battery
Charging specifications： USB Type-C，+5V
Product volume：79*103*31mm
Bracket Specifications： All-in-one foldable stand
Transistor Tester:
Automatically identify and measure various transistors, including NPN & PNP triode, N-channel and P-channel MOSFET, JFET, diodes, double diodes, thyristors, as well as resistors, inductors, capacitors, etc. passive components.
Automatic detection of pin definitions
Digital Oscilloscope:
Real-time sampling rate 10MS/s, bandwidth 500Khz
Maximum measurement of a 400V voltage signal
With complete trigger function (automatic, single, regular)
Equipped with an efficient key, AUTO, the measured waveform can be displayed without cumbersome adjustment
Comes with 1KHz calibrated square wave
Function Signal Generator:
6 kinds of signal waveforms: sine wave, square wave, pulse wave, triangle wave, ramp wave, DC
Output frequency adjustable 1-100KHz
Output voltage adjustable 3.3v
Output duty ratio adjustable 0.100%
Tool Box:
Automatically analyze NEC protocol infrared code
Other function modes: include circuit continuity test, 0~40V input voltage measurement, PWM output, -~32V Zener diode measurement, DS!8B20 temperature sensor measurement, DHT11 temperature, and humidity sensor measurement, etc.
Packing List:
1 x DSO-TC3
1 x Adapter
1 x User's manual
1 x P6100 high-voltage probe
1 x Type-C charging cable
1 x Ordinary Probe
1 x Packing box
3 x Test hook
